Sinusoidal Functions & Graphs

What are the key features of sinusoidal graphs?

  • A sinusoidal graph is of the form

    • space y equals a sin left parenthesis b x right parenthesis plus d

    • space y equals a cos left parenthesis b x right parenthesis plus d

  • The y-intercept is at the point where x equals 0

    • left parenthesis 0 comma space d right parenthesis for space y equals a sin left parenthesis b x right parenthesis plus d

    • left parenthesis 0 comma space a space plus space d right parenthesis for space y equals a cos left parenthesis b x right parenthesis plus d

  • The period of the graph is the length of the interval of a full cycle

    • This is fraction numerator 360 degree over denominator b end fraction

  • The maximum value is y space equals space a space plus space d

    • You can find this by letting sin open parentheses b x close parentheses equals 1 or cos open parentheses b x close parentheses equals 1

  • The minimum value is y space equals space minus a space plus space d

    • You can find this by letting sin open parentheses b x close parentheses equals negative 1 or cos open parentheses b x close parentheses equals negative 1

  • The principal axis is the horizontal line halfway between the maximum and minimum values

    • This is y space equals space d

  • The amplitude is the vertical distance from the principal axis to the maximum value

    • This is the value of a

Graph of sine and cosine functions showing amplitude, period, and vertical shift with equations y=asin(bx)+d and y=acos(bx)+d, in red and blue.
Example of sinusoidal graphs and their key features

Worked Example

a) Sketch the graph space y equals 3 sin left parenthesis 2 x right parenthesis plus 1 for the values space 0 less or equal than x less or equal than 360.

2-2-3-ib-ai-sl-sinusoidal-graphs-a-we-solution

b) State the equation of the principal axis of the curve.

2-2-3-ib-ai-sl-sinusoidal-graphs-b-we-solution

c) State the period and amplitude.

2-2-3-ib-ai-sl-sinusoidal-graphs-c-we-solution
