Nuclide notation

  • Nuclide notation is a standard shorthand used in chemistry to provide detailed information about a specific atom or ion.

  • It indicates the number of protons, neutrons, and electrons

The layout

Diagram of a chemical element symbol "X" with labels: "A" for atomic mass above, "Z" for atomic number below, and "C" for charge to the right.
The layout of nuclide notation

  • A - Mass number:

    • The number at the top left

    • It is the total number of protons + neutrons in the nucleus

  • Z - Atomic number:

    • The number at the bottom left

    • It is the number of protons

    • The atomic number is unique to each element

  • X - Element symbol:

    • The symbol for the element

    • For example:

      • Sodium is Na

      • Chlorine is Cl

      • Magnesium is Mg

  • C - Charge:

    • The charge is written at the top right

    • If there is no charge written, the atom is neutral with a charge of 0

    • The charge is used to determine the number of electrons in an ion

  • For example, the nuclide notation for a sodium ion (Na+) is:

Sodium element symbol "Na" with atomic number 11 and atomic mass 23, displayed with a plus sign indicating a positive ion.
The nuclide notation of a sodium ion

  • This shows that a sodium ion has:

    • A mass number of 23

    • An atomic number of 11

    • A chemical symbol of Na

    • A charge of 1+

Determining protons and electrons

  • You can use the nuclide notation to work out the number of each subatomic particle

How to find the number of protons

  • The number of protons is the atomic number, Z

How to find the number of electrons

  • For a neutral atom:

    • There is no charge shown on the nuclide notation

    • So, the number of electrons is the same as the number of protons

  • For an ion

    • There is a charge shown on the nuclide notation

    • A positive charge shows that an atom has lost electrons

      • A 1+ charge means 1 electron has been lost

      • A 2+ charge means 2 electrons have been lost

    • A negative charge shows that an atom has gained electrons

      • A 1- charge means 1 electron has been gained

      • A 2- charge means 2 electrons have been gained

Worked Example

Determine the number of protons and electrons in:

  1. A chlorine-35 atom open parentheses Cl presubscript 17 presuperscript 35 close parentheses

[2]

  1. A sulfide ion open parentheses scriptbase straight S to the power of 2 minus end exponent end scriptbase presubscript 16 presuperscript 32 close parentheses

[2]

Answer:

  1. The chlorine-35 atom:

  • Protons:

    • The atomic number is 17

    • So, there are 17 protons

[1 mark]

  • Electrons:

    • The atom is neutral

    • So, the number of electrons equals the number of protons

    • So, there are 17 electrons

[1 mark]

  1. The sulfide ion:

  • Protons:

    • The atomic number is 16

    • So, there are 16 protons

[1 mark]

  • Electrons:

    • The ion has a 2- charge

    • It has gained 2 electrons

    • So, the number of electrons = number of protons + 2

    • So there are 16 + 2 = 18 electrons

[1 mark]

Determining neutrons

How to find the number of neutrons

  • The mass number is the number of protons plus neutrons

  • The number of neutrons, n, can be calculated by:

number of neutrons = mass number - atomic number

Worked Example

Determine the number of protons, neutrons and electrons in:

  1. A potassium atom open parentheses straight K presubscript 19 presuperscript 39 close parentheses

[3]

  1. A magnesium ion open parentheses scriptbase Mg to the power of 2 plus end exponent end scriptbase presubscript 12 presuperscript 24 close parentheses

[3]

Answer:

  1. The potassium atom:

  • Protons

    • The atomic number is 19

    • So, there are 19 protons

[1 mark]

  • Electrons

    • The atom is neutral

    • So, the number of protons = the number of electrons

    • So, there are 19 electrons

[1 mark]

  • Neutrons

    • The mass number is 39

    • The atomic number is 19

    • The number of neutrons = mass number - atomic number

    • So, there are 39 - 19 = 20 neutrons

[1 mark]

  1. The magnesium ion:

  • Protons

    • The atomic number is 12

    • So, there are 12 protons

[1 mark]

  • Electrons

    • The ion has a 2+ charge

    • So, it has lost 2 electrons

    • So, the number of electrons = number of protons - 2

    • So, there are 12 - 2 = 10 electrons

[1 mark]

  • Neutrons

    • The mass number is 24

    • The atomic number is 12

    • The number of neutrons = mass number - atomic number

    • So, there are 24 - 12 = 12 neutrons

[1 mark]

  • With the right information, the number of neutrons equation can be rearranged to determine the mass number or atomic number:

mass number = number of neutrons + atomic number

atomic number = mass number - number of neutrons
