Synoptic Exam Questions (AQA AS Chemistry): Exam Questions

Exam code: 7404

2 hours11 questions
1a2 marks

An unknown sample of pure magnesium is analysed using a time-of-flight (TOF) mass spectrometer. The sample is ionised by electron impact to form Mg+ ions.

Explain why magnesium has a higher melting point than sodium.

1b3 marks

The first ionisation energy of magnesium is higher than that of aluminium.

State the full electron configuration of a magnesium atom and use it to explain why this is the case.

1c3 marks

In the mass spectrometer, a 25Mg+ ion travels along a 1.50 m flight tube. The ion takes 5.58 x 10-6 s to reach the detector.

Calculate the kinetic energy, in J, of one 25Mg+ ion.

(The Avogadro constant, L = 6.022 × 1023 mol-1)

1d1 mark

The mass spectrum of the sample showed three peaks with the following abundances:

m/z

Relative abundance

24

79.0

25

10.0

26

11.0

Calculate the relative atomic mass of this sample of magnesium. Give your answer to one decimal place.

1e2 marks

A different ion with a mass of 4.32 x 10-26 kg is accelerated to the same kinetic energy as the 25Mg+ ion.

Deduce whether this ion will take a longer or shorter time to travel through the flight tube. Explain your answer.

2a2 marks

Butane (C4H10) is a saturated hydrocarbon used as a fuel in camping stoves.

Butane is a member of the alkane homologous series. State two characteristics of a homologous series.

2b1 mark

Write a balanced equation for the complete combustion of butane gas.

2c4 marks

A mass of 5.25 g of butane gas is burned completely in oxygen. The carbon dioxide gas produced is collected at a temperature of 50 °C and a pressure of 105 kPa.

Calculate the volume of carbon dioxide gas produced, in dm3.
(The ideal gas constant R = 8.31 J K-1 mol-1)

2d1 mark

Butane exists as structural isomers. The isomer, 2-methylpropane, is also used as a fuel.

Draw the skeletal formula of 2-methylpropane.

2e4 marks

The enthalpy of combustion of 2-methylpropane is -2869 kJ mol-1.

Use the mean bond enthalpies in the table to calculate the enthalpy of combustion for butane (C4H10) and suggest a reason, based on bonds, why the values for the two isomers are different.

Bond

Bond Enthalpy / kJ mol⁻¹

C–H

413

C–C

347

O=O

498

C=O

805

O–H

464

3a3 marks

A chemist is investigating reactions of 3-bromopropan-1-ol, shown below.

Structural formula of 1-bromo-2-propanol: three carbon chain with bromine on first carbon, hydroxyl group on third. Hydrogen atoms fill remaining bonds.

In the first experiment, 3-bromopropan-1-ol is heated with an excess of aqueous sodium hydroxide. The C–Br bond is broken and a new organic product, propane-1,3-diol, is formed.

Outline the mechanism for this reaction.

Include curly arrows, relevant lone pairs and dipoles.

3b3 marks

The chemist wants to confirm that the bromide ion has been produced.

Describe a chemical test that could be carried out on the resulting solution to confirm the presence of bromide ions.

Include the reagents used and the expected observation.

3c2 marks

The reaction in part (a) is repeated using 3-chloropropan-1-ol.

The rate of reaction is observed to be significantly slower.

Explain this difference in rate.

3d3 marks

Explain why propane-1,3-diol has a significantly higher boiling point (214 °C) than 3-bromopropan-1-ol (162 °C).

3e1 mark

In a second experiment, 3-bromopropan-1-ol is heated with hot, ethanolic potassium hydroxide. This causes an elimination reaction to occur.

Draw the displayed formula of the organic product of this elimination reaction.

4a1 mark

Geraniol is a primary alcohol found in rose oil. Its structure is shown below.

Chemical structure of geraniol, showing two isopropenyl groups and an alcohol group (OH) at the end of a hydrocarbon chain.

Geraniol is heated under reflux with an excess of acidified potassium dichromate(VI). A new product, Z, is formed.

Name the functional group in product Z that is formed from the alcohol group in geraniol.

4b1 mark

State the expected colour change during this reaction.

4c2 marks

The chemist wants to confirm that the reaction has occurred. The product Z is separated from the reaction mixture.

Describe a chemical test, other than using Tollens' reagent or Fehling's solution, that would give a positive result with product Z but a negative result with the starting material, geraniol.

4d2 marks

The chemist performs another test by shaking a sample of geraniol with bromine water.

State the expected observation and name the type of reaction occurring.

4e2 marks

In the reaction in part (a), the dichromate(VI) ion, Cr2O72-, is converted to the Cr3+ ion.

Deduce the oxidation state of chromium in the Cr2O72- ion and write a balanced half-equation for the conversion of Cr2O72- in acidic solution to Cr3+ ions.

4f2 marks

Another naturally occurring alcohol is linalool, shown below, which is a structural isomer of geraniol.

Chemical structure of linalool.

Explain why linalool would not react with acidified potassium dichromate(VI).

5a2 marks

Strontium is a Group 2 element that reacts with nitrogen gas at high temperatures to form an ionic compound, strontium nitride.

Strontium has a higher first ionisation energy than barium but a lower first ionisation energy than calcium.

Explain why strontium has a higher first ionisation energy than barium.

5b1 mark

The nitride ion is formed when a nitrogen atom gains three electrons.

Write the full electron configuration for a nitride ion (N3-).

5c5 marks

A 3.55 g sample of pure strontium nitride is added to 200 cm3 of deionised water. It reacts completely according to the equation below. The resulting solution is transferred to a 250 cm3 volumetric flask and made up to the mark with deionised water.

Sr3N2 (s) + 6H2O (l) → 3Sr(OH)2 (aq) + 2NH3 (aq)

A 25.0 cm3 sample of this strontium hydroxide solution is then titrated with 0.150 mol dm-3 hydrochloric acid.

Calculate the volume of hydrochloric acid, in cm3, required to reach the end-point.

5d3 marks

State and explain the shape of the ammonia molecule, NH3.
