Conservation of Linear Momentum (College Board AP® Physics 1: Algebra-Based): Exam Questions

2 hours30 questions
1a
Sme Calculator
1 mark

State the principle of conservation of momentum for an isolated system.

1b
Sme Calculator
4 marks
Two blocks, A and B, of mass m on a horizontal surface. Block A moves right at 2 m/s; Block B moves left at 4 m/s.

Figure 1

Two identical blocks, each of mass m, slide toward each other along a horizontal surface with negligible friction. Block A moves to the right at 2 m/s and Block B moves to the left at 4 m/s, as shown in Figure 1. After the collision, Block A moves to the left at 3 m/s.

i) Calculate the speed of Block B after the collision.

ii) Indicate the direction of motion of Block B after the collision.

1c
Sme Calculator
2 marks

i) Identify the system by drawing a circle around the objects in Figure 1 for which the total momentum is constant.

ii) Calculate the velocity of the center of mass of the two-block system before the collision.

1d
Sme Calculator
2 marks

Indicate whether the velocity of the center of mass of the two-block system increases, decreases, or remains constant after the collision. Justify your answer.

2a
Sme Calculator
2 marks

Describe the difference between an elastic collision and an inelastic collision.

2b
Sme Calculator
2 marks
Two identical balls on a horizontal surface. Before the collision, the ball on the left moves to the right with velocity v, and the ball on the right is stationary. After the collision, the ball on the left is stationary, and the ball on the right moves to the right with velocity v.

Figure 1

A ball of mass m is sliding toward a stationary identical ball with speed v. After the collision, the first ball comes to rest and the second ball slides away with speed v, as shown in Figure 1.

Indicate whether the collision is elastic or inelastic. Justify your answer.

2c
Sme Calculator
4 marks
Two balls on a horizontal surface, the ball on the left has mass 2m and the ball on the right has mass m. Before the collision, the 2m ball moves to the right with velocity v, and the m ball is stationary. After the collision, the balls move to the right together with an unknown velocity.

Figure 2

A ball of mass 2m is sliding toward a stationary ball of mass m with speed v. After the collision, the balls stick together and continue to move in the same direction, as shown in Figure 2.

i) Determine the speed of the balls after the collision in terms of v.

ii) Indicate whether the collision is elastic or inelastic. Justify your answer.

3a
Sme Calculator
1 mark

Two ice skaters are initially at rest. Skater A has a mass of 50 kg, and Skater B has a mass of 75 kg. They push off each other and move in opposite directions.

State the name of this type of interaction.

3b
Sme Calculator
3 marks

The impulse received by Skater A is  JA and the impulse received by Skater B is  JB.

Is the magnitude of  JA greater than, less than, or equal to the magnitude of  JB? Justify your answer.

3c
Sme Calculator
3 marks

After the push, the velocity of Skater A is 3 m/s.

Using conservation of momentum, determine the velocity of Skater B after the push.

3d
Sme Calculator
3 marks

The push happens at time t0. On the axes provided, sketch and label a graph of the velocity of the skaters as a function of time.

Graph with labelled axes; vertical axis is "Velocity (m/s)" and horizontal axis is "Time (s)" with points 0, t0, and 2t0 marked.
4a
Sme Calculator
2 marks
Before the collision, a 3 kg object moves to the right with velocity v0 toward a stationary 2 kg object. After the collision, the 3 kg object moves with speed 2 m/s at an angle 30° above the horizontal, the 2 kg object moves with speed v at an angle 30° below the horizontal.

Figure 1

A 3 kg puck is moving with speed v0 before colliding with a stationary 2 kg puck. Figure 1 shows the velocities of the pucks after the collision.

The arrow in Figure 2 represents the total momentum of the pucks immediately before the collision.

An 8 by 8 grid with dashed lines with a dot at the center and an arrow of 2 units in length pointing right.

Figure 2

On the dot in Figure 3, draw an arrow to represent the total momentum of the pucks immediately after the collision.

A grid of small squares with dashed lines, featuring a single black dot at the centre intersection of the grid.

Figure 3

4b
Sme Calculator
4 marks

i) Calculate the final speed v of the 2 kg puck by considering the total momentum of the system in the y-direction.

ii) Calculate the initial speed v0 of the 3 kg puck by considering the total momentum of the system in the x-direction.

5a
Sme Calculator
2 marks
Two carts on a track: Cart 1 moves right with velocity v0 towards stationary Cart 2, which has a spring attached to it.

Figure 1

A group of students have two carts, Cart 1 and Cart 2, each of known mass m1 and m2, respectively. The carts are placed on a straight horizontal track. Cart 1 is given an initial speed v0 toward the right. Cart 2 is initially at rest and has a spring attached to it, as shown in Figure 1. Cart 1 collides with Cart 2.

The group of students want to determine if the collision between the carts is elastic or inelastic at different speeds. Describe an experimental procedure to collect data that would allow the students to test their idea. Include any steps necessary to reduce experimental uncertainty.

5b
Sme Calculator
2 marks

Describe how the collected data should be analyzed to determine if the collision between the carts is elastic or inelastic at different speeds.

1a
Sme Calculator
3 marks
Two blocks on a line: Block 1 (mass M1) moves right with velocity v0 towards Block 2 (mass M2), both positioned on a horizontal surface.

Figure 1

Block 1 of mass M1 slides to the right along a horizontal surface with speed v0 toward Block 2 of mass M2, which is initially at rest, as shown in Figure 1. When Block 1 collides with Block 2, the blocks stick together. Friction between the blocks and the surface is negligible.

If Block 2 is much less massive than Block 1 (M2  M1), estimate the approximate speed of the two-block system after the collision in terms of v0. Justify your estimate using qualitative reasoning beyond referencing equations.

1b
Sme Calculator
3 marks

Starting with conservation of momentum, derive an equation for vf, the speed of the two–block system after the collision, in terms of M1, M2, and v0. Begin your derivation by writing a fundamental physics principle or an equation from the reference information.

1c
Sme Calculator
2 marks

If Block 2 is much less massive than Block 1, does the equation you derived in part b) agree with your qualitative reasoning from part a)? Justify why or why not.

2a
Sme Calculator
3 marks
Two blocks on a horizontal surface; Block A (6 kg) moving left to right towards Block B (2 kg) at time t = 0, with motion lines indicating speed.

Figure 1

At time t = 0, Block A slides along a horizontal surface toward Block B, which is initially at rest, as shown in Figure 1. The masses of blocks A and B are 6 kg and 2 kg, respectively. The blocks collide elastically at t = 1.0 s and, as a result, the magnitude of the change in kinetic energy of Block B is 9 J. All frictional forces are negligible.

i) Determine the speed of Block B immediately after the collision.

ii) Determine the speed of Block A immediately after the collision.

2b
Sme Calculator
2 marks

The arrow in Figure 2 represents the velocity of the center of mass of the two-block system immediately after the collision.

An 8 by 8 grid with dashed lines with a dot at the center and an arrow of 1.5 units in length pointing right.

Figure 2

The dots in Figure 3 represent Block A and B respectively.

Two grids, labeled Block A (left) and Block B (right), each with a black dot at the center.

Figure 3

On the dots in Figure 3, draw arrows to represent the velocities of Block A and Block B immediately after the collision.

  • If the velocity is zero, write “zero” next to the dot.

  • The velocity, if it is not zero, must be represented by an arrow starting on, and pointing away from, the dot.

  • The length of the arrows, if not zero, should reflect the magnitude of the velocity relative to the arrow in Figure 2.

2c
Sme Calculator
4 marks
Graph showing position vs time with lines for Block A, Block B, and Centre of Mass. Block A starts at 0, Block B at 2. Time spans 0 to 2 seconds.

Figure 4

The graph shown in Figure 4 represents the positions x of Block A, Block B, and the center of mass of the two-block system as functions of t between t = 0 and t = 1.0 s.

On the graph in Figure 4, draw and label three lines to represent the positions of Block A, Block B, and the center of mass of the two-block system as functions of t between t = 1.0 s and t = 2.0 s. Each line should be distinctly labeled.

2d
Sme Calculator
3 marks

A student considers whether the line drawn for the center of mass in part c) would change if the blocks stuck together after the collision rather than colliding elastically. They make the following claim:

“The slope of the line drawn for the center of mass of the two-block system would be less steep”.

Justify whether or not the student’s claim is correct.

3a
Sme Calculator
4 marks
Diagram of a spring-mass system with a block labelled M, connected to a wall by a spring. Marked points show equilibrium and extremes at -A1 and A1.

Figure 1

Block 1 of mass M is oscillating with amplitude A1 at the end of a spring with spring constant k. The other end of the spring is attached to a wall, as shown in Figure 1. Friction between the block and the floor is negligible.

A block of mass 2M is dropped on to the block of mass M as it passes through equilibrium. New amplitudes A2 and -A2 are marked.

Figure 2

Block 2 of mass 2M is dropped from rest and sticks to Block 1 as it passes through its equilibrium position, as shown in Figure 2. The two-block system oscillates with amplitude A2.

i) Derive an expression for the velocity v of Block 1 at the equilibrium position before Block 2 is dropped, in terms of k, M, and A1. Begin your derivation by writing a fundamental physics principle or an equation from the reference information.

ii) Starting with conservation of momentum, derive an expression for the velocity of the two-block system immediately after Block 2 sticks to Block 1 in terms of v.

3b
Sme Calculator
2 marks

Indicate whether amplitude A2 is greater than, less than, or equal to amplitude A1 by writing one of the following:

  • A2>A1

  • A2=A1

  • A2<A1

Justify your answer using qualitative reasoning beyond mathematical derivations or expressions.

4a
Sme Calculator
2 marks

Block 1 of mass m1 and Block 2 of mass m2 are sliding along a horizontal frictionless surface when they collide at time tc. Before the collision, the blocks slide toward each other. After the collision, the blocks slide together.

Indicate whether the kinetic energy of the two-block system after the collision is greater than, equal to, or less than the kinetic energy before the collision. Justify your answer using qualitative reasoning beyond referencing equations.

4b
Sme Calculator
3 marks
Graph showing velocity as a function of time for two blocks. Before tc, Block 1 has velocity +4v and Block 2 has velocity -v. After tc, Blocks 1 and 2 have velocity +v.

Figure 1

The graph in Figure 1 shows the velocities of the blocks as a function of time.

Using the graph in Figure 1, derive an expression for the ratio of the mass of Block 2 to the mass of Block 1, m2m1. Begin your derivation by writing a fundamental physics principle or an equation from the reference information.

4c
Sme Calculator
3 marks

Does the graph in Figure 1 agree with your qualitative reasoning from part a)? Use the expression derived in part b) to justify your answer.

5
Sme Calculator
3 marks
Diagram showing a launching device propelling a projectile to the right at a speed of vx towards a block hanging by a string from the ceiling.

Figure 1

A block of mass Mb is suspended from the ceiling using a string with negligible mass. A projectile of mass Mp is fired horizontally from a launching device with speed vx into the block, as shown in Figure 1. While the projectile is in the launching device, the impulse given to it is  Jp. When the projectile strikes the block, the impulse given to the block is Jb. After the collision, the projectile becomes embedded in the block.

If the projectile is much less massive than the block (Mp  Mb), estimate the approximate magnitude of the impulse given to the block in terms of  Jp. Justify your estimate using physical principles.

1a
Sme Calculator
3 marks
Two experiments: A clay ball hits Block A on a table in Experiment A; a rubber ball hits Block B on a table in Experiment B.

Figure 1

A student conducts an experiment using a clay ball of mass m and a rubber ball of the same mass. Each ball is thrown horizontally with speed v0 toward two identical blocks of mass M that are at rest at the edge of identical tables, as shown in Figure 1. After each collision, the blocks fall to the floor. Friction between the blocks and the table is negligible.

In Experiment A, the clay ball sticks to Block A. In Experiment B, the rubber ball bounces off of Block B at a speed of vr. After the collisions, Block A lands a horizontal distance dA, and Block B lands a horizontal distance dB from the table's edge.

Indicate whether dA is greater than, less than, or equal to dB by writing one of the following:

  • dA > dB

  • dA = dB

  • dA < dB

Justify your answer using qualitative reasoning beyond referencing equations.

1b
Sme Calculator
3 marks

Starting with conservation of momentum, derive an equation for the ratio of the speed of Block A after the collision to the speed of Block B after the collision, vAvB. Express your answer in terms of m, M, v0 and vr. Begin your derivation by writing a fundamental physics principle or an equation from the reference information.

1c
Sme Calculator
2 marks

If the balls are much less massive than the blocks (m  M), does the equation you derived in part b) agree with your qualitative reasoning from part a)? Justify why or why not.

2a
Sme Calculator
3 marks
Diagram showing two scenarios: t = 0 and t > tc. At t=0, mass m1  compresses the spring by a distance delta x. At t>tc, the spring is at its uncompressed length at x = 0 and mass m1 is moving to the right where it collides with a smaller mass m2. m1 and m2 move together to the right at velocity v.

Figure 1

Block 1 of mass m1 is held at rest while an ideal spring of spring constant k is compressed by x. Block 2 has mass m2 where m2 < m1. At time t = 0, Block 1 is released. At time t = tC , the spring is no longer compressed and Block 1 immediately collides with and sticks to Block 2. The two-block system moves with constant speed v, as shown in Figure 1. Friction between the blocks and the surface is negligible.

Derive an expression for the velocity of the two-block system after the collision in terms of m1, m2, k and x. Begin your derivation by writing a fundamental physics principle or an equation from the reference book.

2b
Sme Calculator
2 marks

In another scenario with the same equipment, Block 1 is used to compress the spring by the same amount as before, and Block 2 is placed in the same initial position. When the spring is released, Block 1 remains attached to the spring as it collides with Block 2. The velocity of Block 2 immediately after the collision is v2.

Indicate whether v2 is greater than, less than, or equal to vf by writing one of the following:

  • v2 > vf

  • v2 = vf

  • v2 < vf

Briefly justify your answer. In your justification, include qualitative reasoning beyond mathematical derivations or expressions.

3a
Sme Calculator
4 marks
A ball launched at angle φ with initial velocity v0 towards a pendulum. The pendulum hangs from length L and swings up by angle θ after the collision with the ball.

Figure 1

A clay ball of mass m is launched at an angle ϕ above the horizontal with initial speed v0. At the moment it reaches the highest point in its trajectory and is moving horizontally, it collides with and sticks to a wooden block of mass M, as shown in Figure 1. The block is suspended from a light string of length L. The block and the clay then swing up to a maximum height h0 above the block’s initial position and make an angle θ with the vertical.

i) Starting with conservation of momentum, derive an expression for the velocity of the block-clay system immediately after the collision. Express your answer in terms of m, M, v0 and ϕ. Begin your derivation by writing a fundamental physics principle or an equation from the reference book.

ii) Starting with conservation of energy, derive an expression for the speed of the clay ball immediately before it strikes the block. Express your answer in terms of m, M, L, θ and physical constants, as appropriate. Begin your derivation by writing a fundamental physics principle or an equation from the reference book.

3b
Sme Calculator
3 marks

Figure 4 shows a momentum diagram that represents the velocity and mass of the clay-block system immediately after the clay ball strikes the block.

Draw shaded rectangles to complete the momentum diagrams in Figure 2 and Figure 3 to represent the velocity and mass of the clay ball and block, respectively, immediately before the clay ball strikes the block.

  • Positive values of velocity are above the zero line (“0”), and negative values of velocity are below the zero line.

  • Shaded regions should start at the lines representing zero velocity and mass.

  • Represent any velocity that is equal to zero with a distinct line on the zero line.

  • The relative height and width of each shaded region should reflect the magnitude of the velocity and mass, respectively, consistent with the scale used in Figure 4.

Three graphs showing momentum against mass. Left: Initial momentum of clay. Centre: Initial momentum of block. Right: Final momentum of clay-block system.

Figure 2‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎Figure 3‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎ ‎Figure 4

3c
Sme Calculator
2 marks

In a second experiment, a steel ball is used instead of a clay ball. The steel ball is launched at the same speed and angle, but instead collides elastically with the block. The block swings up to a maximum height h0'.

Indicate whether h0' is greater than, less than, or equal to h0 by writing one of the following:

  • h0' > h0

  • h0' = h0

  • h0' < h0

Justify your answer.

4a
Sme Calculator
3 marks
Plunger moves from position A to position F with a block at A and E; textured section between C and D.

Figure 1

Blocks 1 and 2, each of mass m, are placed on a horizontal surface at points A and E, respectively, as shown in Figure 1. The surface is frictionless except for the region between points C and D.

In the time interval t = tA to t = tB, a mechanical plunger pushes Block 1 with a constant horizontal force of magnitude Fp. At point B, Block 1 loses contact with the plunger and continues moving to the right with speed vB. In the time interval t = tC to t = tD, Block 1 moves over the rough surface where the coefficient of kinetic friction between the block and the surface is μ. At point D, Block 1 is moving to the right with speed vD. At point E, Block 1 collides with and sticks to Block 2, after which the two-block system continues moving across the surface, eventually passing point F at time tF.

Two blocks on a line; left image shows block 1 at D moving with velocity vD and block 2 at E with zero velocity; right image shows blocks together at E.

Figure 2

Figure 2 shows the location of the center of mass of the two-block system just before and during the collision.

The dots in Figure 3 represent the blocks while they are in contact during the collision, and the center of mass of the two-block system.

Three grids labelled Block 1, Block 2, and Two-block system, each with a central black dot on a 6x6 grid.

Figure 3

On each of the dots in Figure 3, draw arrows to indicate the direction of the net force, if any, exerted on each block, and the two-block system.

  • If the net force is zero for either block or the two-block system, write “zero” next to the dot.

  • The net force must be represented by a distinct arrow starting on, and pointing away from, the appropriate dot.

  • The length of the arrows, if not zero, should reflect the magnitude of the net force relative to the other arrows.

4b
Sme Calculator
4 marks

On the axes provided below, sketch and label a graph of the velocity of the center of mass of the two-block system as a function of time, from time tA until the blocks pass point F at time tF. The times at which Block 1 reaches points A through F are indicated on the time axis.

Graph with time on the x-axis and velocity of center of mass on the y-axis, showing six points from tA to tF along the time axis.
5a
Sme Calculator
2 marks
Two carts with mass M. Cart 2 contains a plunger-spring system. Before recoil: carts at rest next to each other, spring compressed within Cart 2. After recoil: carts move apart, spring extended.

Figure 1

A group of students have two carts, Cart 1 and Cart 2, each of identical, unknown mass M. The carts are initially at rest and placed next to each other on a horizontal track. Cart 2 contains a compressed spring which can be released by pressing a switch on top of the cart. When the switch is pressed, the spring expands and pushes a plunger outward, causing the two carts to recoil, as shown in Figure 1. Blocks of different known masses can be attached to each cart.

The group of students is asked to determine whether the total momentum of the system is conserved. The students have access to equipment that can be found in a typical school physics laboratory.

i) Indicate quantities that could be measured by the students that would allow them to determine whether the total momentum of the system is conserved during the recoil.

ii) Briefly describe a method to reduce experimental uncertainty for the measured quantities indicated in part a)i).

5b
Sme Calculator
2 marks

i) Indicate what quantities the students could graph on the horizontal and vertical axes to create a linear graph that can be used to determine whether the total momentum of the system is conserved.

ii) Briefly describe how the graph will be analyzed to determine whether the total momentum of the system is conserved.

5c
Sme Calculator
4 marks
Two carts, 1 and 2, of mass M on a track. Cart 2, with a spring and a block on top, is against a wall to the left. Cart 1 is to the right of Cart 2, with 4 blocks on top.

Figure 2

In a later experiment, Cart 2 is placed next to a wall. When the switch is pressed, the spring expands and the plunger pushes on the wall, causing Cart 2 to move towards Cart 1, as shown in Figure 2. Cart 1 is initially at rest. After the collision, the two carts stick together and move along the track with speed v. Blocks of identical, known mass can be attached to Cart 1 and Cart 2, as long as the total mass of the system remains constant. The spring constant k of the spring in Cart 2 is unknown. When the spring is contained within the cart, it is compressed by a fixed distance x from its equilibrium position.

The students are asked to determine the value of the spring constant of the spring. The students measure the combined mass M1,B of Cart 1 and the blocks, the combined mass M2,B of Cart 2 and the blocks, and the final speed of the two-cart-block system.

The students measure the fixed value x = 0.062 m. The students repeat the experiment using different numbers of blocks on each cart and collect the data shown in Table 1.

Table 1

Combined mass of Cart 1 and blocks, M1,B (kg)

Combined mass of Cart 2 and blocks, M2,B (kg)

Final speed of the two-cart-block system, v (m/s)

1.750

0.500

0.410

1.500

0.750

0.505

1.250

1.000

0.585

1.000

1.250

0.650

0.750

1.500

0.720

0.500

1.750

0.775

The students create a graph with v2 plotted on the vertical axis.

i) Label the horizontal axis of Figure 3 with a measured or calculated quantity. Include units, as appropriate. The graphed quantities should yield a linear graph that can be used to determine the spring constant k of the spring.

ii) On the grid provided in Figure 3, create a graph of the quantities indicated in part c)i).

  • Clearly label the horizontal axis with a numerical scale

  • Plot the corresponding data points on the grid

  • Any columns added to Table 1 for scratch work will not be scored

Blank graph with vertical axis labelled v² in units of m²/s², ranging from 0.0 to 0.6 with evenly spaced gridlines. Horizontal axis is blank with spaces for "Quantity" and "Units (if appropriate)" labelled.

Figure 3

iii) Draw a best-fit line to the data graphed in part c)ii).

5d
Sme Calculator
2 marks

Using the line drawn in part c)iii) and the measured value x = 0.062 m as needed, calculate the spring constant k of the spring.
